Mencari supplier terpercaya, barang ready stock dengan penawaran harga terbaik?
Kami merupakan Distributor dan Supplier resmi sparepart Vacuum Pump / Pompa Vakum merek Value di berbagai toko sparepart yang tersebar di seluruh indonesia.
Untuk info harga dan penawaran, hubungi kami di:
No WA : 08111332678
No WA : 08111662679
Email : This email address is being protected from spambots. You need JavaScript enabled to view it.
Single Stage
| Flow Rate 50Hz |
1.8 CFM |
2.5 CFM |
3.5 CFM |
6.0 CFM |
8.0 CFM |
| Flow Rate 50Hz |
51 L/min |
70 L/min |
100 L/min |
170 L/min |
226 L/min |
| Flow Rate 60Hz |
2.0 CFM |
3.0 CFM |
4.0 CFM |
7.0 CFM |
9.0 CFM |
| Flow Rate 60Hz |
57 L/min |
84 L/min |
113 L/min |
198 L/min |
254 L/min |
| Ultimate Vacuum Partial Preassure |
2 Pa |
2 Pa |
2 Pa |
2 Pa |
2 Pa |
| Ultimate Vacuum Total Preassure |
150 micron |
150 micron |
150 micron |
150 micron |
150 micron |
| Power |
1/4 HP |
1/4 HP |
1/3 HP |
1/2 HP |
3/4 HP |
| Inlet Port |
1/4" SAE |
1/4" SAE |
1/4" & 3/8" SAE |
1/4" & 3/8" SAE |
1/4" & 3/8" SAE |
| Oil Capacity |
250 ml |
250 ml |
250 ml |
415 ml |
660 ml |
| Dimensions |
290x124x224 mm |
290x124x224 mm |
318x124x234 mm |
338x138x244 mm |
395x145x357 mm |
| Weight |
6.6 Kg |
7.1 Kg |
8.0 Kg |
9.9 Kg |
14.6 Kg |
Dual Stage
| Flow Rate 50Hz |
1.5 CFM |
2.5 CFM |
4.5 CFM |
6.0 CFM |
8.0 CFM |
10.0 CFM |
| Flow Rate 50Hz |
42 L/min |
70 L/min |
128 L/min |
170 L/min |
226 L/min |
283 L/min |
| Flow Rate 60Hz |
1.8 CFM |
3.0 CFM |
5.0 CFM |
7.0 CFM |
9.0 CFM |
12.0 CFM |
| Flow Rate 60Hz |
50 L/min |
84 L/min |
142 L/min |
198 L/min |
254 L/min |
340 L/min |
| Ultimate Vacuum Partial Preassure |
2x10 Pa |
2x10 Pa |
2x10 Pa |
2x10 Pa |
2x10 Pa |
2x10 Pa |
| Ultimate Vacuum Total Preassure |
15 micron |
15 micron |
15 micron |
15 micron |
15 micron |
15 micron |
| Power |
1/4 HP |
1/3 HP |
1/2 HP |
3/4 HP |
1 HP |
1 HP |
| Inlet Port |
1/4" SAE |
1/4" SAE |
1/4" & 3/8" SAE |
1/4" & 3/8" SAE |
1/4" & 3/8" SAE |
1/4" & 3/8" SAE |
| Oil Capacity |
200 ml |
200 ml |
325 ml |
580 ml |
500 ml |
590 ml |
| Dimensions |
308x124x224 mm |
318x124x234 mm |
338x138x244 mm |
395x145x257 mm |
395x145x257 mm |
395x145x257 mm |
| Weight |
7.5 Kg |
8.5 Kg |
10.4 Kg |
15.8 Kg |
16.2 Kg |
16.7 Kg |
